Nom de la série : Optical Test Equipment
Nom : MH-CP Coaxial Parabolic Mirror
MHNV®️ parabolic mirror is a type of surface mirror. It is widely used in astronomical observation optical instruments, spectral detection, astronomical telescope systems, aiming instruments, beam expanders, infrared systems, concentrated solar energy systems, projection systems, and transmitting/detecting equipment.
Paramètres
| Coaxial Parabolic Reflector | |||
| Clear Aperture (mm) | Focal Length(mm) | Surface Figure Accurac | Coating |
| 200 | 800 | RMS Better than 入/30@632.8nm | Available Coatings: Au, Ag, or Al |
| 200 | 1000 | RMS Better than 入/30@632.8nm | Available Coatings: Au, Ag, or Al |
| 200 | 1200 | RMS Better than 入/30@632.8nm | Available Coatings: Au, Ag, or Al |
| 200 | 1600 | RMS Better than 入/30@632.8nm | Available Coatings: Au, Ag, or Al |
| 200 | 2000 | RMS Better than 入/30@632.8nm | Available Coatings: Au, Ag, or Al |
| 300 | 2000 | RMS Better than 入/30@632.8nm | Available Coatings: Au, Ag, or Al |
| 350 | 3000 | RMS Better than 入/30@632.8nm | Available Coatings: Au, Ag, or Al |
| 400 | 4000 | RMS Better than 入/30@632.8nm | Available Coatings: Au, Ag, or Al |
| 500 | 5000 | RMS Better than 入/30@632.8nm | Available Coatings: Au, Ag, or Al |
Étiquette chaude :
Coaxial Parabolic Mirror,Coaxial Parabolic Reflector,Parabolic Mirror
